Iskra ISPRO-K BSR 75/440 (3 0), Class I,II / Type 1,2 / B,C, Surge Protection Device (SPD) with Remote Contact, 3 Pole 75kA,440VAC, DIN Rail Mount
Specifications
| Iskra Doo part number | ISPRO-K BSR 75/440 (3 0) |
| Nominal Voltage | 440VAC |
| No of Poles | 3 |
| Category IEC / EN / VDE | Class I,II / Type 1,2 / B,C |
| Location of use | Main Distribution Boards |
| Protection modes | L/N-PE, L-PEN, L-N, N-PE High Energy MOV and GDT |
| Protective element | MOV GDT |
| Surge discharge rating | Imax up to 75 kA, or 25kA per pole |
| Internal protection and safety | Thermal disconnector in each MOV |
| Standards | IEC/EN 61643-11 |
